Wedge wire screen - no-clogging & less pressure drop

Wedge wire screen
Wedge wire sand screen

Wedge wire screen is a welded structure with V-shaped profile wire welded to support ribs. It combines superior weld strengths & precision slot tolerances. The distance between two neighboring wires mainly depends on the formation and sand size. Continuous slots allows for high production and no-clogging. Appropriate slot spacing is a vital element in selection an appropriate sand screen. It is widely used in water, oil and gas wells.

V shaped wire screen can be used as standalone or as outer jacket for wire wrapped pipe based screen or pre-packed sand screen. Keystone shaped slots provides free flow and optimize sand control.

Product description:

  • Material: AISI304/AISI316L stainless steel wire or high strength carbon steel wire;
  • Inside diameter: 2”, 3”, 4”, 5”, 6” & 8”;
  • Minimum slot opening: 0.05mm;
  • Profile wire width: 1.5mm to 3.7mm;
  • Support rib width: 2.3mm to 3.7mm.

Feature & Advantage:

  • Precision and uniform slot spacing;
  • High open area;
  • Resist plugging and prevent sand from damaging pumps;
  • Minimum drawdown and less energy usage by a pump;
  • Minimum pressure drop.
Wedge wire screen specification
Profile V Wire
Width (mm) 1.50 1.50 2.30 2.30 1.80 3.00 3.70 3.30
Height (mm) 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30
Support Wire
Width (mm) 2.30 2.30 3.00 3.70 3.30 Round Wire
Height (mm) 2.70 3.60 4.70 5.60 6.30 2.5mm to 5mm
